REDEL-compatible medical plastic circular push-pull self-locking connector PAG PKG 1P/2P/4 pin. Lightweight, quick release connector for medical devices and healthcare equipment applications.
The REDEL-compatible PAG and PKG medical plastic circular connector is designed for healthcare equipment and medical device applications requiring lightweight, safe, and reliable connections. Available in 1P, 2P, and 4 pin configurations, this push-pull self-locking connector enables quick release and secure mating for critical medical systems.
Manufactured with high-quality medical-grade plastic housing, the connector is lightweight, durable, and resistant to impact and chemical exposure. Its ergonomic push-pull locking mechanism ensures fast connection and disconnection, making it ideal for hospital equipment, monitoring systems, diagnostic instruments, and portable medical devices.
| Feature | Description |
|---|---|
| Series | PAG / PKG |
| Pin Count | 1P / 2P / 4 Pin |
| Connector Type | Circular Medical Plastic Connector |
| Locking Mechanism | Push-pull self-locking |
| Housing Material | Medical-grade plastic |
| Contact Material | Copper alloy |
| Contact Plating | Gold plated |
| Mating Cycles | High durability mating performance |
| Rated Voltage | Model dependent |
| Operating Temperature | -20°C to +85°C |
| Applications | Medical devices, hospital equipment, diagnostic systems |
Compatible with REDEL medical connector systems
Lightweight medical-grade plastic housing
1P / 2P / 4 pin configurations available
Push-pull self-locking quick release mechanism
Safe and reliable connection for medical equipment
Ergonomic design for easy handling
High mating cycle durability
Suitable for portable and stationary medical systems
Patient monitoring systems
Diagnostic and imaging equipment
Surgical instruments
Portable medical devices
Laboratory instruments
Hospital and clinical electronic equipment
This medical plastic push-pull connector ensures safe, fast, and reliable electrical connections in healthcare environments. The lightweight design reduces equipment load while maintaining strong mechanical stability. The quick release push-pull system allows rapid device replacement and maintenance without compromising connection security.
Designed for high-reliability medical systems, the PAG/PKG connector provides stable signal and power transmission for critical healthcare applications.
Individual protective packaging
Bulk order support
OEM customization available
Custom Cable assembly services available
Technical documentation upon request
