The 4P13+1 Pneumatic & Electrical Self‑Locking Aviation Connector is a high‑performance M25 plastic quick release connector designed for medical aesthetics, industrial automation, and hybrid pneumatic‑electrical systems. Featuring 4 pneumatic ports, 13 power contacts plus 1 auxiliary, and an 11+2 signal adapter layout, this rugged connector delivers reliable multi‑function connectivity with self‑locking precision and rapid mating/disconnection. Ideal for medical gas delivery, aesthetic devices, robotics, and complex control panels requiring combined air and signal routing in a single robust aviation‑style plug.
Model: 4P13+1 Pneumatic‑Electrical Aviation Connector
Connector Type: Hybrid Pneumatic & Electrical Self‑Locking Aviation Plug
Series / Standard: M25 Plastic Quick Connector Series
Configuration:
• 4 Pneumatic Interfaces – Air/Gas Delivery
• 13 Power Contacts + 1 Auxiliary Port – Combined power routing
• 11+2 Signal Adapter Layout – Signal & control lines
Housing Material:
High‑strength engineering plastic (M25 standard) with durable finish
Locking Mechanism:
Self‑locking quick‑connect system for secure and fast engagement
Sealing & Protection:
Dust and splash resistance (IP rating dependent on assembly)
Operating Temperature Range:
‑20°C to +80°C (application dependent)
Voltage Rating:
Up to 300V DC/AC (electrical contacts)
Current Rating:
Up to 3A per electrical contact (depending on wire gauge)
Pneumatic Pressure Rating:
Up to 10 bar (146 psi) – suitable for medical air and general pneumatic applications
Contact Material:
Copper alloy with corrosion‑resistant plating for reliable electrical performance
Durability:
3,000 mating cycles (typical)
Cable Compatibility:
Compatible with multi‑core electrical and pneumatic tubing assemblies; custom harnessing available
Use Cases:
• Medical aesthetic devices (air supply + control signals)
• Pneumatic actuators in automation systems
• Robotic end‑of‑arm tooling with air & signal lines
• Industrial control panels combining power and pneumatics
• Laboratory and instrumentation equipment
Key Features:
✔ Combined pneumatic and electrical interface in one connector
✔ Fast self‑locking mechanism for secure connections
✔ Plastic M25 construction for lightweight, corrosion resistance
✔ Versatile 11+2 signal routing for complex systems
✔ Engineered for durability and repeated connects
