FSG Right-Angle Aviation Plug 0T/1T/2T Series 360° Adjustable Waterproof Circular Connector

FSG right-angle aviation plug 0T/1T/2T series with 360° adjustable cable exit and waterproof design. Reliable push-pull self-locking circular connector for industrial, medical, and aerospace applications.

The FSG right-angle aviation plug 0T/1T/2T series is designed with a 360° adjustable cable exit, allowing flexible routing in tight or complex installation environments. Its waterproof design ensures reliable performance in harsh industrial, medical, and aerospace applications.

The circular push-pull self-locking mechanism provides fast, secure mating and prevents accidental disconnection. Built with durable metal housing and high-quality contacts, the FSG connector ensures excellent electrical performance, mechanical stability, and resistance to vibration and environmental exposure.

Technical Specifications

Feature	Description
Series	FSG 0T / 1T / 2T
Connector Type	Right-Angle Aviation Plug Circular Connector
Cable Exit	360° Adjustable
Locking Mechanism	Push-Pull Self-Locking
Waterproof Rating	IP65 / IP67 (depending on model)
Housing Material	Metal Alloy
Contact Material	Copper Alloy
Contact Plating	Gold Plated
Operating Voltage	Up to 250V
Temperature Range	-40°C to +125°C
Applications	Industrial, medical, aerospace, instrumentation

Key Features

Right-angle aviation plug for flexible installation
360° adjustable cable exit for versatile routing
Push-pull self-locking mechanism for secure mating
Waterproof design for IP65/IP67 protection
Durable metal housing and gold-plated contacts
High vibration and mechanical impact resistance
Compatible with FSG 0T/1T/2T series systems
Ideal for industrial, aerospace, and medical applications

Applications

Aerospace and defense electronics
Industrial automation and instrumentation
Medical device and diagnostic equipment
Test and measurement systems
Communication and control devices
Harsh environment electronic installations

Performance Advantages

The FSG right-angle aviation plug with 360° adjustable cable exit ensures maximum flexibility in cable routing while maintaining robust electrical performance. Its push-pull self-locking design allows quick and reliable connection, while the waterproof construction protects against moisture, dust, and environmental hazards.

This connector is engineered for applications requiring precision, durability, and adaptability in tight or demanding spaces.
