LEMO Compatible FAG Short Fixed Connector FWG 0B 1B 2B Panel Mount Socket

We manufacture high-precision FAG short fixed connectors and FWG aviation plugs fully compatible with LEMO B Series interface standards.

Designed for secure panel mounting applications, these push-pull self-locking circular connectors provide stable signal and power transmission in compact equipment structures.

Available sizes include:

• 0B Series

• 1B Series

• 2B Series

Product Overview

The FAG short fixed connector (panel mount type) is engineered for PCB or front panel installation. The FWG cable plug mates securely with the panel socket using a reliable push-pull self-locking mechanism.

Typical applications include:

• Medical monitoring systems

• Diagnostic imaging devices

• Industrial control systems

• Test & measurement instruments

• Audio & broadcast equipment

• Robotics and automation devices

Technical Specifications

Series: 0B / 1B / 2B (Compatible Type)
Connector Type: Push-Pull Self-Locking Circular Connector
Mounting Type: Panel Mount (FAG Fixed Socket)
Mating Plug: FWG Cable Plug
Contact Configuration: 2 – 32 Pins (depending on series)
Contact Type: Solder / PCB Tail
Rated Voltage: 50V – 500V
Rated Current: 1A – 20A
Contact Resistance: ≤ 5 mΩ
Insulation Resistance: ≥ 1000 MΩ
Shielding: 360° EMC Shielded
Protection Level: IP50 (Standard) / IP68 (Optional Sealed Type)
Shell Material: Brass with Chrome Plating
Insulator Material: PPS / PEEK
Operating Temperature: -45°C to +125°C
Mating Cycles: ≥ 5000 cycles
Compliance: ROHS & REACH

Key Features

• Fully compatible with LEMO B series interface

• Short body fixed design for compact panels

• Secure push-pull self-locking system

• High precision CNC machined housing

• Excellent EMI/RFI shielding performance

• Durable and vibration resistant

• Multiple keying options to prevent mis-mating

• Custom pin layout and Cable assembly supported

Customization Services

We provide:

• Custom pin configuration

• PCB tail length adjustment

• Waterproof sealing option

• Logo laser marking

• Overmolded cable assemblies

• Small batch prototype production

• Large scale OEM manufacturing

Manufacturing Advantages

• Advanced CNC machining equipment

• Strict tolerance and dimensional inspection

• 100% electrical continuity testing

• Stable bulk production capacity

• Competitive factory pricing

Our LEMO compatible FAG and FWG connectors deliver reliable performance in high-precision medical and industrial environments.

For technical drawings, samples, or wholesale pricing, contact us for professional engineering support.
